EXM800, ZONE/PGM EXPANSION MODULE (SECOLINK)

Product type: zone expansion module
Number of wired zones on the board: up to 8 (depending on the number of PGMs selected)
Number of PGMs (open collector) on the board: up to 7 (depending on the number of zones selected)
Data bus protocol: KRBUS
Sensor Loop Types: NC, NO, NC/EOL, NO/EOL, NC/DEOL, NO/DEOL
Maximum communication cable distance between module and control panel: 300 m
Power supply voltage: 9 – 14 V DC
Voltage measurement in module: yes
Current consumption: 15 mA
Maximum input PGM current: -0.075 A
Maximum total input current of all PGMs: -0.5 A
Overall dimensions WxH: 67 mm x 50 mm
Environmental Compliance: ROHS
Operating temperature: -10°C to +50°C
